Meanwell 12VDC Power Supply 150W 10A LPV-150 Input Volt 180-305Vac Output Volt 12V15V24V36V48V IP67waterproof for outdoor work UL&EMC List
#12VDC Power Supply 150W 10A Single Output Switching Meanwell LPV-150-12
| Specification Datasheet | Meanwell Power Supply LPV-150-12 | |
|---|---|---|
| #Output | DC Voltage | 12V |
| Working Voltage | Rated Current | 10A |
| Current Range | 0~10A | |
| Rated Power | 120W | |
| Ripple Noise (max. Note.2 | 120mVp-p | |
| Voltage TOLERANCE Note.3 | ±5.0% | |
| LINE REGULATION | ±1.0% | |
| LOAD REGULATION | ±2.0% | |
| SETUP, RISE TIME Note.6 | LPV-150: 500ms, 50ms / 230VAC 500ms, 50ms / 277VAC | |
| HOLD UP TIME (Typ.) | LPV-150: 18ms/230VAC 20ms/277VAC at full load | |
| #Input | VOLTAGE RANGE Note.4 | 180 ~ 305VAC 254 ~ 431VDC |
| FREQUENCY RANGE | 47 ~ 63Hz | |
| EFFICIENCY (Typ.) | 87% | |
| AC CURRENT | 1.7A/230VAC 1.5A/277VAC | |
| INRUSH CURRENT(Typ.) | Blank type COLD START 60A(twidth=900μs measured at 50% Ipeak) at 230VAC L type COLD START 75A(twidth=900μs measured at 50% Ipeak) at 115VAC |
|
| MAX. No. of PSUs on 16A CIRCUIT BREAKER. | Blank type 2 units (circuit breaker of type B) / 3 units (circuit breaker of type C) at 230VAC L type 1 units (circuit breaker of type B) / 2 units (circuit breaker of type C) at 115VAC |
|
| LEAKAGE CURRENT | 0.25mA / 240VAC | |
| #Protection | Over Load | 110 ~ 150% rated output power Protection type : Hiccup mode, recovers automatically after fault condition is removed |
| Over Voltage | 13.5 ~ 18V Protection type : Shut down o/p voltage, re-power on to recover | |
| #Environment | WORKING TEMP. | -25 ~ +70°C (Refer to "Derating Curve") |
| WORKING HUMIDITY | 20~90% RH non-condensing | |
| STORAGE TEMP., HUMIDITY | -40~+80°C, 10~ 95% RH | |
| TEMP. COEFFICIENT | ±0.03%/°C (0 ~ 40°C for LPV-150-12 | |
| VIBRATION | 10~500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes | |
| #Safety & EMC Standards | SAFETY STANDARDS | UL8750,CSA C22.2 No 250.13-12,UL879,CSA C22.2 No.207-M89,BIS IS15885(for LPV-150-12,24 only),EAC TP TC 004, IP67, IEC62368-1, BS EN/EN62368-1 approved |
| WITHSTAND VOLTAGE | I/P-O/P: 3KVAC | |
| ISOLATION RESISTANCE | I/P-0/P:>100M Ohms / 500VDC/25°C/ 70% RH | |
| EMC EMISSION | Compliance to BS EN/EN55032 (CISPR32) Class B, BS EN/EN61000-3-2 Class A(≤80% load), BS EN/EN61000-3-3, EAC TP TC 020 | |
| EMC IMMUNITY | Compliance to BS EN/EN61000-4-2,3,4,5,6,8,11; BS EN/EN55035, light industry level, EAC TP TC 020 | |
| MTBF | 3361.2K hrs min. Telcordia SR-332 (Bellcore) ; 391.9Khrs min. MIL-HDBK-217F (25°C) | |
| DIMENSION | 191*63*37.5mm (L*W*H) | |
| PACKING | LPV-150: 0.74Kg;20pcs/15.8Kg/0.95CUFT | |
| Note | 1. All parameters NOT specially mentioned are measured at 230VAC(115VAC for LPVL) input, rated load and 25°C of ambient temperature. 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor. | |
| 3. Tolerance : includes set up tolerance, line regulation and load regulation. | ||
| 4. Derating may be needed under low input voltage. Please check the static characteristics for more details. | ||
| 5. The power supply is considered as a component that will be operated in combination with final equipment. Since EMC performance will be affected by the complete installation, the final equipment manufacturers must re-qualify EMC Directive on the complete installation again. | ||
| (as available on https://www.meanwell.com//Upload/PDF/EMI_statement_en.pdf) | ||
| 6. Length of set up time is measured at first cold start. Turning ON/OFF the power supply may lead to increase of the set up time. | ||
| 7. Suitable for indoor use or outdoor use without direct sunlight exposure. | ||
| 8. The ambient temperature derating of 3.5°C/1000m with fanless models and of 5°C/1000m with fan models for operating altitude higher than 2000m(6500ft). 9. For any application note and IP water proof function installation caution, please refer our user manual before using. | ||
| https://www.meanwell.com/Upload/PDF/LED_EN.pdf | ||
| 10. This product is not intended for LED lighting luminaire applications in the EU.(In the EU the LPF/NPF/XLG series are recommended.) ※ Product Liability Disclaimer:For detailed information, please refer to https://www.meanwell.com/serviceDisclaimer.aspx | ||
#Meanwell Power Supply Specifications
12VDC Power Supply Meanwell LPV-150W-spec
#Meanwell Power Supply User’s Manual
#Meanwell Power Supply LPV-150 Safety&EMC List
#SAFETY STANDARDS
UL8750,CSA C22.2 No 250.13-12,UL879,CSA C22.2 No.207-M89,BIS IS15885(for LPV-150-12,24 only),EAC TP TC 004, IP67, IEC62368-1, BS EN/EN62368-1 approved
#EMC EMISSION
Compliance to BS EN/EN55032 (CISPR32) Class B, BS EN/EN61000-3-2 Class A(≤80% load), BS EN/EN61000-3-3, EAC TP TC 020
#EMC IMMUNITY
Compliance to BS EN/EN61000-4-2,3,4,5,6,8,11; BS EN/EN55035, light industry level, EAC TP TC 020
