12VDC Power Supply 100W Meanwell LPV-100W picture
12VDC Power supply 100W Meanwell LPV-100-12 size sheetpng
12VDC Power supply 100W Meanwell LPV-100-12 datasheet

12VDC Power Supply 100W 8.5A Meanwell LPV-100-12(100W-12V)

Original price was: $40.50.Current price is: $38.50.

Product Features

12VDC Power Supply 100W 8.5A Single Output Switching Meanwell Power Supply 100-12(100W-12V)

Constant voltage design
Universal AC input/ Full range
Fully encapsulated with IP67 level(Note.7)
Withstand 300VAC surge input for 5 seconds
Protections: Short circuit /Overload Over voltage
Fully isolated plastic case
Cooling by free air convection
100% full load burn-in test
Low cost, high reliability
Suitable for LED related fixture or appliance
(such as LED Decoration or Advertisement devices)(Note.11)
2 years warranty

Specifications

#12VDC Power Supply 100W 8.5A Single Output Switching Meanwell Power Supply 100-12(100W-12V)

Specification DatasheetMeanwell Power Supply LPV-100-12
#OutputDC Voltage12V
Working VoltageRated Current8.5A
Current Range0~8.5A
Rated Power102W
Ripple Noise (max. Note.2 120mVp-p
Voltage TOLERANCE Note.3 ±5.0%
LINE REGULATION ±1.0%
LOAD REGULATION ±2.0%
SETUP, RISE TIME Note.62000ms, 25ms / 230VAC 2000ms, 25ms / 115VAC
HOLD UP TIME (Typ.) 50ms/230VAC 14ms/115VAC at full load
#InputVOLTAGE RANGE Note.490 ~ 264VAC 127 ~ 370VDC
FREQUENCY RANGE 47 ~ 63Hz
EFFICIENCY (Typ.) 83%
AC CURRENT 2.2A/115VAC 1.2A/230VAC
INRUSH CURRENT(Typ.) COLD START 75A(twidth=700μs measured at 50% Ipeak) at 230VAC
MAX. No. of PSUs on 16A CIRCUIT BREAKER. 2 units (circuit breaker of type B) / 3 units (circuit breaker of type C) at 230VAC
LEAKAGE CURRENT 0.25mA / 240VAC
#ProtectionOver Load110 ~ 150% rated output power
Protection type : Hiccup mode, recovers automatically after fault condition is removed
Over Voltage13.8 ~ 16.2V
Protection type : Shut down o/p voltage, re-power on to recover
#EnvironmentWORKING TEMP.-25 ~ +70°C (Refer to "Derating Curve")
WORKING HUMIDITY20~90% RH non-condensing
STORAGE TEMP., HUMIDITY-40~+80°C, 10~ 95% RH
TEMP. COEFFICIENT±0.03%/°C (0~50°C)
VIBRATION10~500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes
#Safety & EMC StandardsSAFETY STANDARDSUL8750,CSA C22.2 No 250.13-12,UL879,CSA C22.2 No.207-M89,BIS IS15885(Note12), EAC TP TC 004,IP67, IEC62368-1 , BS EN/EN62368-1 approved
WITHSTAND VOLTAGEI/P-O/P: 3KVAC
ISOLATION RESISTANCE1/P-0/P:>100M Ohms / 500VDC/25°C/ 70% RH
EMC EMISSIONCompliance to BS EN/EN55032 (CISPR32) Class B, BS EN/EN61000-3-2 Class A(≤80% load), BS EN/EN61000-3-3, EAC TP TC 020
EMC IMMUNITYCompliance to BS EN/EN61000-4-2,3,4,5,6,8,11; BS EN/EN55035, light industry level, EAC TP TC 020
MTBF4497.1K hrs min. Telcordia SR-332 (Bellcore) ; 681.6Khrs min. MIL-HDBK-217F (25°C)
DIMENSION190*52*37mm (L*W*H)
PACKING0.61Kg;20pcs/13.2Kg/0.57CUFT
Note1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25°C of ambient temperature.
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
3. Tolerance : includes set up tolerance, line regulation and load regulation.
4. Derating may be needed under low input voltage. Please check the static characteristics for more details.
5. The power supply is considered as a component that will be operated in combination with final equipment. Since EMC performance will be affected by the
complete installation, the final equipment manufacturers must re-qualify EMC Directive on the complete installation again.
(as available on https://www.meanwell.com//Upload/PDF/EMI_statement_en.pdf)
6. Length of set up time is measured at first cold start. Turning ON/OFF the power supply may lead to increase of the set up time.
7. Suitable for indoor use or outdoor use without direct sunlight exposure.
8. The ambient temperature derating of 3.5°C/1000m with fanless models and of 5°C/1000m with fan models for operating altitude higher than 2000m(6500ft). 9. Products sourced from the Americas regions may not have the TUV/BIS/CCC logo. Please contact your MEAN WELL sales for more information.
10. For any application note and IP water proof function installation caution, please refer our user manual before using.
https://www.meanwell.com/Upload/PDF/LED_EN.pdf
11. This product is not intended for LED lighting luminaire applications in the EU and China.(In the EU and China the LPF/NPF/XLG/XLC/XLN series
are recommended.)
12. R-41027766 (GZ factory) only for 12V,24V / R-62002178 (ID factory) for 5V~48V
※ Product Liability Disclaimer:For detailed information, please refer to https://www.meanwell.com/serviceDisclaimer.aspx

#Other Optional Voltage
5V 12V 15V 24V 36V 48V

#Applications:
Factory Automation Equipment/Home Interiors/Industrial Equipment
Sign Lighting/Stage & Theaters/Strip Lights/Trade Shows

#Meanwell Power Supply Specifications

12VDC Power supply 100W MeanwellLPV-100-datasheet
#Meanwell Power Supply User’s Manual

Meanwell Powe Supply user's Manual
